QSC K8.2 是一款2000W的可攜式 PA 音箱，專為音樂表演、會議、及各類小型活動而設計。這款音箱不僅功能多樣，還具備高效能的音質，能夠提供清晰、強勁的聲音表現，適合用作主音箱或監聽音箱。
擁有105°的覆蓋範圍和122 dB的連續聲壓級.
K8.2 配備了內建的數位信號處理器（DSP）、三路輸入混音器以及易於使用的LCD介面，讓使用者能夠快速設置和調整音效。無論是演講者、音樂家、講師還是視聽提供者，都能輕鬆獲得強勁而清晰的聲音。
此包裝包括：
- QSC K8.2 音箱
- 電源線
- - - -
SPECIFICATIONS
Configuration: Multi-purpose, 2-way active loudspeaker
LF Transducer: 203 mm (8-inch), cone
HF Transducer: 35.6 mm (1.4-inch) titanium diaphragm compression driver
Frequency Response (-6 dB): 59 Hz - 20 kHz
Frequency Range (-10 dB): 55 Hz - 20 kHz
Nominal Coverage Angle: 105° Axisymetric
Maximum Rated SPL:
- 128 dB @1 M, peak
- 122 dB @ 1 M, continuous
Amplifier:
- Cooling: Low-noise, variable speed fan
-
Class D:
- Peak: 1800 W (LF)
- 225 W (HF)
Controls:
- Power
- 3 × Level
- Rotary encoder (push)
- 2 × selection buttons
Indicators:
- Monochrome LCD Display: 45 mm × 25.4 mm (1.75-inch × 1-inch)
- 2 × Power LED (front and rear)
- 3 × Input Signal LED
- Input A Mic selected LED
- Input B Hi-Z selected LED
- Limiter active LED
Connectors:
- 2 × locking XLR/F ¼⁻ᶦⁿᶜʰ combo (Mic/Line Input and Hi-Z/Line Input)
- 1 × 3.5 mm TRS (Stereo Input)
- 2 × XLR/M (Loop-thru Output)
- 1 × XLR/M (Mix Output)
- 1 × locking IEC power connector
AC Power Input: Universal power supply 100 – 240 VAC, 50 – 60 Hz
AC Power Consumption 1/8th Power:
- 100 VAC: 2.1 A
- 120 VAC: 1.9 A
- 240 VAC: 1.1 A
AC Power Consumption - Standby: 0.2 A at any voltage
Enclosure Details:
- Enclosure: Impact Resistant ABS
- Attachment Points: 2 × M10 threaded inserts plus Pull-Back
- Color: Black (RAL 9011)
- Grille: 18 Gauge powered coated steel, internal cloth lining
Speaker Dimensions (H×W×D): 449 × 280 × 269 mm (17.7 × 11 × 10.6 in)
Carton Dimensions (H×W×D): 500 × 380 × 368 mm (19.7 × 15 × 14.5 in)
Net Weight: 12.2 kg / 27 lb
Shipping Weight: 14.4 kg / 31.7 lb
